Femtosort

Sorting rice became easier by targeted center ejection and reverse sorting technology. New FEMTOSORT generation machine gives best results with more optimized features like energy conservation.

Reverse Object Sorting
Reverse Object Sorting

Rejecting Good rice in final rejection through Reverse sorting feature decreases the wastage of good grains.Rejection Ratio > 40:1 (Bad: Good)

Targeted Centre Rejection
Targeted Centre Rejection

Targeting centre region of individual rice controls excess rejection of good rice. Due to the optimized ON time of the ejector, air consumption is reduced by around 20% and valve life expectancy is increased in billions.

AI Image Capture
AI Image Capture

Artificial Intelligence image capture helps to capture high speed grains and analyze fine parts of every grain. It helps to make user friendly operation.

Live Performance Monitoring
Live Performance Monitoring

Through this feature live performance of this machine can be monitored. Real-time Output Tonnage and batch-wise production data can be monitored and stored. This helps with the efficient utilization of the machine.

About Femtosort

Our FEMTOSORT machine is equipped with Artificial Intelligence Technology. With this Artificial Intelligence and Mixed color spectrum, we can accurately detect and remove even the mild chalky, lightest yellow, minute spot defects to meet export quality Requirements. With the combination of Target-hitting technology with High-speed ejectors, we can reduce wastage even at a higher ever capacity. With a High-performance Feeder system and specially designed chute, the machine's capacity is substantially increased. With the User-Friendly Android-based interface, we can achieve the machine's optimum performance in a straightforward manner. Advanced feedback systems and intelligence dust suction features enable the machine to provide consistent performance and enhanced productivity. The machine is connected through 4G networking for providing Quick online support to Customers.

Supported Commodities
Models & Technical Specification
Model FEMTO 5 FEMTO 6 FEMTO 8 FEMTO 10
Processing Capacity (Tons/Hr) 3 to 4 4 to 5 6 to 8 7.5 to 10
Chute (No of Channels) 128 + 64 + 64 + 64 192 + 64 + 64 + 64 256 + 128 + 64 + 64 320 + 128 + 128 + 64
Sorting Accuracy > 99.6% > 99.6% > 99.6% > 99.6%
Rejection Ratio ≥ 40:1 ≥ 40:1 ≥ 40:1 ≥ 40:1
Voltage (v) AC220 /50 HZ AC220 /50 HZ AC220 /50 HZ AC220 /50 HZ
Power required (KVA) 7.5 7.5 10 12
Air pressure required Kg/cm2 6.1 -8.2 6.1 -8.2 6.1 -8.2 6.1 -8.2
Air required (CFM) 120 130 150 160
Weight Max (kg) 1170 1458 1800 2403
Frame Type 5 FRAME 6 FRAME 8 FRAME 10 FRAME
Dimension in mm (L x W x H) 2216 x 1715 x 1850 2866 x 1715 x 1900 3350 x 1700 x 2000 4277 x 1715 x 2002
Dimension in Feet ' Inches " (L x W x H) 7' 5 " x 5' 7.5" x 6' 1" 9' 3" x 5' 7.5" x 6' 4" 11' x 5' 7" x 6' 8" 14' 1" X 5' 8" X 6' 8"
Terms and conditions
  • Sorting performance varied depends upon Variety , Input contamination and condition of raw material. The capacity range given is for 2 % (Dark defects) contamination on tested.
  • Capacity means " Throughput" = Output + Rejection
  • Air consumption will be more in case of higher rejection rate for raw materials with higher contamination
  • Technical Specifications may change without prior information due to continuous R&D
Result
Input

Output

Rice with Condemnation

Rice with Condemnation

Black Rice

Tip Black Rice

Yellow Rice

Light Yellow Rice

Chalky Rice

Good Rice
