Flow meter is a highly versatile weighing system which measures Tonnage and Production for a Batch. This helps to find the efficiency of Milling process from Paddy pre cleaner I/P to Colour sorter O/P. FMFM 060240 used for bulk measurement in silo feeding and discharge. Hence we can measure the remaining quantity inside Silo.
Product Detail
Paddy/Rice
| Model | FGFM0620 | FGFM0820 | FGFM30120 | FGFM60240 | |
|---|---|---|---|---|---|
| Functional | Capacity (Max) (TPH) | 6.0 | 8.0 | 30.0 | 60.0 |
| Accumulated weight in Metric Tons (max) | 999.0 | 999.0 | 999.0 | 999.0 | |
| Electrical | Operating Voltage | 230VAC, 50Hz | |||
| Power Required | 250W | ||||
| Electronic | Human Machine Interface | 7" Touch screen | 7" Touch screen | 7" Touch screen | 9" Touch screen |
| Batch Weight (approx) | 10 | 20 | 120 | 240 | |
| Weighing accuracy per batch Grams (+/-) | 20 | 20 | 40 | 60 | |
| Data Storage | 15 days data | 15 days data | 15 days data | 30 days data | |
| Pneumatic | Data Transfer | SMS Through Modem | |||
| Air Pressure required | 5.5 ~ 6.5 Bar | ||||
| Air Volume required | 2 CFM | ||||
| Mechanical | Dimension LxWxH (Ft, In) | 2'8" x 2'10" x 2'6" | 2'8" x 2'10" x 2'6" | 2'0" x 4'1" x 8'1" | 4'1" x 4'1" x 8'1" |
Orange Brings you a very accurate, user-friendly and high-speed blending machine for the industry. VieBland uses a state of the art technology in every component of the blending machine. VieBland uses an imported Load cell which needs fewer number of calibrations in its life span. The accepted level of weighing can be calibrated by the user itself. By understanding the requirement of users we have introduced many interesting features.
